Classify an incomplete vision–language dataset (Oxford‑IIIT Pets) with deep learning

This tutorial demonstrates how to classify samples from an incomplete vision–language dataset using the iMML library. iMML supports robust classification even when some modalities (e.g., text or image) are missing, making it suitable for real‑world multi‑modal data where missingness is common.

We will use the RAGPT algorithm from the iMML classify module on the Oxford‑IIIT Pets dataset and evaluate its performance.

What you will learn:

• How to load a public vision–language dataset (Oxford‑IIIT Pets via Hugging Face Datasets).

• How to adapt this workflow to your own vision–language data.

• How to build a retrieval‑augmented memory bank and prompts with MCR.

• How to train the RAGPT classifier when image or text may be missing.

• How to track metrics during training and evaluate with MCC and a confusion matrix.

# sphinx_gallery_thumbnail_number = 1

# License: BSD 3-Clause License

Step 0: Prerequisites

To run this tutorial, install the extras for deep learning:

pip install imml[deep]

We also use the Hugging Face Datasets library to load Oxford‑IIIT Pets:

pip install datasets

Step 1: Import required libraries

import shutil
from PIL import Image
from lightning import Trainer
import lightning as L
from matplotlib import pyplot as plt
from torch.utils.data import DataLoader
import torch
import os
import pandas as pd
from sklearn.metrics import matthews_corrcoef, ConfusionMatrixDisplay
from sklearn.preprocessing import LabelEncoder
from datasets import load_dataset

from imml.ampute import Amputer
from imml.classify import RAGPT
from imml.load import RAGPTDataset, RAGPTCollator
from imml.model_selection import train_test_mm_split
from imml.retrieve import MCR

Step 2: Prepare the dataset

We use the oxford-iiit-pet-vl-enriched dataset, a public vision–language dataset with images and captions available on Hugging Face Datasets as visual-layer/oxford-iiit-pet-vl-enriched. For retrieval, we will use the MCR class from the retrieve module.

random_state = 42
L.seed_everything(random_state)

# Local working directory (images will be saved here so MCR can read paths)
data_folder = "oxford_iiit_pet"
folder_images = os.path.join(data_folder, "imgs")
os.makedirs(folder_images, exist_ok=True)

# Load the dataset
ds = load_dataset("visual-layer/oxford-iiit-pet-vl-enriched", split="train[:40]")

# Build a DataFrame with image paths and captions. We persist images to disk because
# the retriever expects paths.
n_total = len(ds)
rows = []
for i in range(n_total):
    ex = ds[i]
    img = ex.get("image", None)
    caption = ex.get("caption_enriched", None)
    label = ex.get("label_cat_dog", None)
    img_path = os.path.join(folder_images, f"{i:06d}.jpg")
    try:
        img.save(img_path)
    except Exception:
        img.convert("RGB").save(img_path)
    rows.append({"img": img_path, "text": caption, "label": label})

df = pd.DataFrame(rows)
le = LabelEncoder()
df["class"] = le.fit_transform(df["label"])
df["class"].value_counts()

class
1    29
0    11
Name: count, dtype: int64

Split into 40% bank memory, 40% train and 20% test sets

Xs = [df[["img"]],df[["text"]]]
y = df["class"]
Xs_train, Xs_test, y_train, y_test = train_test_mm_split(Xs, y, test_size=0.2,
                                                         shuffle=True, stratify=y,
                                                         random_state=random_state)
Xs_train, Xs_bank, y_train, y_bank = train_test_mm_split(Xs_train, y_train, test_size=0.5,
                                                         shuffle=True, stratify=y_train,
                                                         random_state=random_state)
print("Xs_train", Xs_train[0].shape)
print("Xs_test", Xs_test[0].shape)
print("Xs_bank", Xs_bank[0].shape)

Xs_train (16, 1)
Xs_test (8, 1)
Xs_bank (16, 1)

Step 3: Simulate missing modalities

To reflect realistic scenarios, we randomly introduce missing data using Amputer. In this case, 60% of training and test samples will have either text or image missing. You can change this parameter for more or less amount of incompleteness.

amputer = Amputer(p=0.6, random_state=random_state)
Xs_train = amputer.fit_transform(Xs_train)
Xs_test = amputer.transform(Xs_test)

Step 4: Generate the prompts using a retriever

RAGPT needs prompts, which are created from a memory bank with a retriever. We use MCR (Multi-Channel Retriever) to construct a memory bank and generate prompts.

modalities = ["image", "text"]
batch_size = 64
estimator = MCR(batch_size=batch_size, modalities=modalities, save_memory_bank=True,
                prompt_path=data_folder, n_neighbors=2, generate_cap=True)
estimator.fit(Xs=Xs_bank, y=y_bank)
memory_bank = estimator.memory_bank_
print("memory_bank", memory_bank.shape)
memory_bank.info()

memory_bank (16, 8)
<class 'pandas.core.frame.DataFrame'>
Index: 16 entries, 26 to 18
Data columns (total 8 columns):
 #   Column             Non-Null Count  Dtype
---  ------             --------------  -----
 0   item_id            16 non-null     int64
 1   img_path           16 non-null     object
 2   text               16 non-null     object
 3   q_i                16 non-null     object
 4   q_t                16 non-null     object
 5   label              16 non-null     int64
 6   prompt_image_path  16 non-null     object
 7   prompt_text_path   16 non-null     object
dtypes: int64(2), object(6)
memory usage: 1.1+ KB

Load generated training and testing prompts.

train_db = estimator.transform(Xs=Xs_train, y=y_train)
print("train_db", train_db.shape)
train_db.head()

test_db = estimator.transform(Xs=Xs_test, y=y_test)
print("test_db", test_db.shape)

train_db (16, 14)
test_db (8, 14)

Step 5: Training the model

Create the loaders.

train_data = RAGPTDataset(database=train_db)
train_dataloader = DataLoader(dataset= train_data, batch_size=batch_size,
                              collate_fn= RAGPTCollator(), shuffle=True)

test_data = RAGPTDataset(database=test_db)
test_dataloader = DataLoader(dataset=test_data, batch_size=batch_size,
                             collate_fn=RAGPTCollator(), shuffle=False)

Train the RAGPT model using the generated prompts. For speed in this demo we train for only 2 epochs using the Lightning library.

trainer = Trainer(max_epochs=2, logger=False, enable_checkpointing=False)
estimator = RAGPT()
trainer.fit(estimator, train_dataloader)

Training: |          | 0/? [00:00<?, ?it/s]
Training:   0%|          | 0/1 [00:00<?, ?it/s]
Epoch 0:   0%|          | 0/1 [00:00<?, ?it/s]
Epoch 0: 100%|██████████| 1/1 [00:06<00:00,  0.15it/s]
Epoch 0: 100%|██████████| 1/1 [00:06<00:00,  0.15it/s]
Epoch 0: 100%|██████████| 1/1 [00:06<00:00,  0.15it/s]
Epoch 0:   0%|          | 0/1 [00:00<?, ?it/s]
Epoch 1:   0%|          | 0/1 [00:00<?, ?it/s]
Epoch 1: 100%|██████████| 1/1 [00:06<00:00,  0.15it/s]
Epoch 1: 100%|██████████| 1/1 [00:06<00:00,  0.15it/s]
Epoch 1: 100%|██████████| 1/1 [00:06<00:00,  0.15it/s]
Epoch 1: 100%|██████████| 1/1 [00:06<00:00,  0.15it/s]

Step 6: Advanced Usage: Track Metrics During Training

As any other model in Lightning, we can modify the internal functions. For instance, we can track loss and compute evaluation metrics during training.

trainer = Trainer(max_epochs=2, logger=False, enable_checkpointing=False)
estimator = RAGPT()
estimator.loss_list = []
estimator.agg_loss_list = []
validation_step = estimator.validation_step

def compute_metric(*args):
    loss = validation_step(*args)
    estimator.loss_list.append(loss)
    return loss
estimator.validation_step = compute_metric

def agg_metric(*args):
    estimator.agg_loss_list.append(torch.stack(estimator.loss_list).mean())
    estimator.loss_list = []
estimator.on_validation_epoch_end = agg_metric

trainer.fit(estimator, train_dataloader, test_dataloader)

Sanity Checking: |          | 0/? [00:00<?, ?it/s]
Sanity Checking:   0%|          | 0/1 [00:00<?, ?it/s]
Sanity Checking DataLoader 0:   0%|          | 0/1 [00:00<?, ?it/s]
Sanity Checking DataLoader 0: 100%|██████████| 1/1 [00:01<00:00,  0.71it/s]


Training: |          | 0/? [00:00<?, ?it/s]
Training:   0%|          | 0/1 [00:00<?, ?it/s]
Epoch 0:   0%|          | 0/1 [00:00<?, ?it/s]
Epoch 0: 100%|██████████| 1/1 [00:06<00:00,  0.15it/s]
Epoch 0: 100%|██████████| 1/1 [00:06<00:00,  0.15it/s]

Validation: |          | 0/? [00:00<?, ?it/s]

Validation:   0%|          | 0/1 [00:00<?, ?it/s]

Validation DataLoader 0:   0%|          | 0/1 [00:00<?, ?it/s]

Validation DataLoader 0: 100%|██████████| 1/1 [00:01<00:00,  0.70it/s]


Epoch 0: 100%|██████████| 1/1 [00:08<00:00,  0.12it/s]
Epoch 0: 100%|██████████| 1/1 [00:08<00:00,  0.12it/s]
Epoch 0:   0%|          | 0/1 [00:00<?, ?it/s]
Epoch 1:   0%|          | 0/1 [00:00<?, ?it/s]
Epoch 1: 100%|██████████| 1/1 [00:06<00:00,  0.14it/s]
Epoch 1: 100%|██████████| 1/1 [00:06<00:00,  0.14it/s]

Validation: |          | 0/? [00:00<?, ?it/s]

Validation:   0%|          | 0/1 [00:00<?, ?it/s]

Validation DataLoader 0:   0%|          | 0/1 [00:00<?, ?it/s]

Validation DataLoader 0: 100%|██████████| 1/1 [00:01<00:00,  0.69it/s]


Epoch 1: 100%|██████████| 1/1 [00:08<00:00,  0.11it/s]
Epoch 1: 100%|██████████| 1/1 [00:08<00:00,  0.11it/s]
Epoch 1: 100%|██████████| 1/1 [00:08<00:00,  0.11it/s]

Step 7: Evaluation

After training, we can evaluate predictions and visualize the results.

preds = trainer.predict(estimator, test_dataloader)
preds = [batch.softmax(dim=1) for batch in preds]
preds = [pred for batch in preds for pred in batch]
preds = torch.stack(preds).argmax(1).cpu()
losses = [i.item() for i in estimator.agg_loss_list]

nrows, ncols = 2,3
test_df = pd.concat(Xs_test, axis=1)
test_df = pd.concat([test_df, y_test.to_frame("label")], axis=1)
test_df = test_df.reset_index(drop=True)
preds = preds[test_df.index]
fig, axes = plt.subplots(nrows, ncols, constrained_layout=True)
for i, (i_row, row) in enumerate(test_df.sample(n=nrows*ncols, random_state=random_state).iterrows()):
    pred = preds[i_row]
    image_to_show = row["img"]
    caption = row["text"]
    real_class = le.classes_[row["label"]]
    ax = axes[i//ncols, i%ncols]
    ax.axis("off")
    if isinstance(image_to_show, str):
        image_to_show = Image.open(image_to_show).resize((512, 512), Image.Resampling.LANCZOS)
        ax.imshow(image_to_show)
    else:
        ax.plot(0.5, 0.5, 'rx', markersize=100, markeredgewidth=10)
    pred_class = le.classes_[pred]
    c = "green" if pred_class == real_class else "red"
    ax.set_title(f"Pred:{pred_class}; Real:{real_class}", **{"color":c})
    if isinstance(caption, str):
        caption = caption.split(" ")
        if len(caption) >=6:
            caption = caption[:len(caption)//2] + ["\n"] + caption[len(caption)//2:]
            caption = " ".join(caption)
        ax.annotate(caption, xy=(0.5, -0.08), xycoords='axes fraction', ha='center', va='top')
    else:
        ax.annotate("X", xy=(0.5, -0.08), xycoords='axes fraction', ha='center', va='top', color="red", fontsize=30)

shutil.rmtree(data_folder, ignore_errors=True)

Predicting: |          | 0/? [00:00<?, ?it/s]
Predicting:   0%|          | 0/1 [00:00<?, ?it/s]
Predicting DataLoader 0:   0%|          | 0/1 [00:00<?, ?it/s]
Predicting DataLoader 0: 100%|██████████| 1/1 [00:01<00:00,  0.70it/s]
Predicting DataLoader 0: 100%|██████████| 1/1 [00:01<00:00,  0.70it/s]

ConfusionMatrixDisplay.from_predictions(y_true=y_test, y_pred=preds)
print("Testing metric:", round(matthews_corrcoef(y_true=y_test, y_pred=preds), 2))

Testing metric: 1.0

Despite using only 40 instances and minimal training, the performance was excellent thanks to the pretrained models.

Summary of results

We first built a memory bank with 40% independent vision-language samples using the iMML retrieve module to generate retrieval-augmented prompts with a multi-channel retriever (MCR). Subsequently, we trained a model using the RAGPT algorithm available in iMML under 25% randomly missing text and image modalities. The model demonstrated strong robustness on the test set.

This example is intentionally simplified, using only 40 instances for demonstration. For stronger performance and more reliable results, the full dataset and longer training should be used.

Conclusion

This example illustrates how iMML enables state-of-the-art performance in classification, even in the presence of significant modality incompleteness in vision-language datasets.
